Feeder Schedule Module

The list of every conduit run ABR routes — each row is a source panel connected to a load.

Last updated July 19, 2026

The Feeder Schedule is the list of every electrical conduit run in your project. Each row is one run — a connection from a source panel to a load — together with its conduit size, type and usage. This is what ABR routes when you click Generate Routes.

The Feeder Schedule panel in the main window

Pick a topic below to dig in.

Table of Contents

The ColumnsWhat each column means — ID, Source, Load, Diameter, Type, Usage, Comments.
Panel ButtonsThe Add Run, Download (export) and Delete buttons on the panel.
The Feeder Schedule WindowThe full editor — search, filters, editable cells and the bottom toolbar.
Diagonal RoutingA straight diagonal preview that skips clash checks — for visualization only.
Import from ExcelLoad a whole feeder schedule from a spreadsheet instead of adding runs by hand.
Parallel IDsRoute several parallel conduits for one run — add a count column and ABR splits it into numbered parallel runs.
Video WalkthroughA short clip of the Feeder Schedule in action.
