Routing Manager

The heart of the app — generate routes and HR boxes, add boxes by hand, steer runs and merge circuits.

Last updated July 20, 2026

Routing Manager is where the work actually happens. Once a design layout is imported, this section turns panels and devices into HR (home-run) boxes and branch routes.

Routing Manager, highlighted in the main window

It has three buttons and one toggle:

Generate Routes — the one-click AI run.
Add HR Box — place a home-run box yourself.
Preferred Routing — tell the router which zones to follow.
Merge Circuits — combine circuits into shared home runs while generating.
